Product Class: Kit

Monarch® HMW DNA Extraction Kit for Tissue

Product Introduction

  • Designed for extraction for long-read sequencing applications from a variety of tissues, bacteria, yeast, insect, amphibian, and more. See related Monarch Genomic DNA Purification Kit (NEB #T3010) for gDNA extraction for general NGS and sequencing (Illumina® and other).
  • Isolate high molecular weight DNA (100 kb to megabase range) from soft organ tissues and bacteria and more for Oxford Nanopore®, PacBio® sequencing
  • Uses unique, innovative technology for fast, user-friendly workflows, only 90 minutes for extraction compared to hours or days.
  • Includes RNase A, Proteinase K, and microtube pestles, for effective RNA removal, digestion of cellular proteins, and sample homogenization.
  • Obtain best-in-class yields of highly-pure and intact DNA
  • For HMW gDNA extraction from cells and blood for long-read sequencing, see related Monarch HMW DNA Extraction Kit for Cells & Blood (NEB #T3050)

Featured Resources:

  • See how the Monarch HMW DNA workflow significantly reduced workflow time in the Cas9 targeted sequencing approach in our joint Technical Note with The Jackson Laboratory.
  • Check out our publication in Biotechniques outlining a simple approach to accurate quantitation of ultra high molecular weight (UHMW) DNA.
  • Review our technical note examining the use and comparison of a novel method to isolate genomic DNA from bacteriophages.
Catalog # Size Concentration
T3060S 5.0 preps
T3060L 50.0 preps

Product Information

Description

The Monarch HMW DNA Extraction Kit for Tissue provides a rapid and reliable process for extracting high molecular weight (HMW), intact genomic DNA from various tissues and bacteria, as well as other sample types including yeast, insect, and amphibian.  The optimized extraction protocol for tissue utilizes pestle homogenization and proteinase K digestion with agitation for sample lysis, followed by a protein removal step and precipitation of the extracted DNA onto the surface of large glass beads.  A slightly modified extraction protocol for bacteria utilizes lysozyme for the efficient lysis of the bacterial cell wall, prior to proteinase K digestion.  DNA size ranges from 50- ≥500 kb for the standard protocols and into the Mb range when the lowest agitation speeds are used for processing soft organ tissues and bacteria. Purified DNA is recovered in high yield with excellent purity, including nearly complete removal of RNA. For tissue and bacteria, the processing time is 90 min. Purity ratios are typically 1.8-1.9 (260/280) for tissue and bacteria, 2.1-2.5 (260/230) for tissue, and 2.1-2.2 (260/230) for bacteria.  Purified HMW DNA is suitable for a variety of downstream applications including long-read sequencing (Oxford Nanopore Technologies® and Pacific Biosciences®), optical mapping (Bionano Genomics®), and linked-read genome assembly.

Validated Sample Types

  • Mouse brain
  • Mouse liver
  • Mouse muscle
  • Mouse kidney
  • Mouse tail
  • Mouse ear punch
  • Rat kidney
  • E. coli
  • B. cereus
  • M. luteus
  • X. laevis
  • S. cerevisiae
  • C. elegans
  • A. aegypti

Visit our input guidelines for more information



Figure 1: Workflow for isolation of HMW DNA from Tissue using the Monarch HMW DNA Extraction Kit





Figure 2: The Monarch HMW DNA Extraction Kit for Tissue efficiently purifies high-quality, HMW DNA from a variety of sample types



HMW genomic DNA extracted with the Monarch HMW DNA Extraction Kit for Tissue. 10 mg frozen rat kidney, 10 mg fresh mouse liver, 20 mg frozen mouse brain, 20 mg fresh mouse muscle, 2 x 109 frozen E. coli cells, 2 x 108 frozen B. cereus cells, 4 mg fresh X. laevis, 3.8 x 108 fresh S. cerevisiae cells and 15 mg frozen A. aegypti were used as inputs for preps. Preps were performed according to the kit instructions with sample agitation at 2000 rpm. A modified workflow was used to process S. cerevisiae preps. 500 ng of DNA from each sample prep was resolved by PFGE (1% agarose gel, 6 V/cm, 13°C for 20 hours, switch times ramped from 0.5-94 seconds on a BioRad CHEF-DR III System). Yield and purity ratios of the individual preps are shown in the accompanying tables. Lambda PFG Ladder (NEB #N0341) was used as a molecular weight standard.



Figure 3: Use of varying agitation speeds during lysis produces tunable fragment length for HMW genomic DNA extracted from soft organ tissues and bacteria



HMW genomic DNA from mouse kidney (10 mg, Figure 3A) and E. coli NEB10 beta (1 x 109 cells, Figure 3B) was purified using the Monarch HMW DNA Extraction Kit for Tissue. Samples were agitated at the indicated speed during the lysis step to control the fragmentation of the DNA. 300 ng (kidney) and 500 ng (E. coli) of DNA for each sample was resolved by PFGE (settings: switch time 0.5 to 94 sec; run time 20 hours at 6 V/cm, angle 120°, temperature 13°C on the BioRad CHEF-DR III System). Lambda PFG Ladder (NEB #N0341) was used as molecular weight standard. Yield, purity ratios and DIN values (kidney) of the individual preps are shown in the accompanying tables

This product is related to the following categories:
Genomic DNA Extraction & Purification Products,
Nucleic Acid Purification Products,

Kit Components

Kit Components

The following reagents are supplied with this product:

NEB # Component Name Component # Stored at (°C) Amount Concentration

Properties & Usage

Protocols, Manuals & Usage

Protocols

  1. Download Quick Protocol Card for Tissue
  2. Protocol for High Molecular Weight DNA (HMW DNA) Extraction from Tissue (NEB #T3060)
  3. Protocol for High Molecular Weight DNA (HMW DNA) Extraction from Bacteria (NEB #T3060)
  4. Protocol for High Molecular Weight DNA (HMW DNA) Extraction from Yeast (NEB #T3060)
  5. Protocol for High Molecular Weight DNA (HMW DNA) Extraction from Phage
  6. Protocol for UHMW DNA Cleanup in the Oxford Nanopore Technologies® UL Library Prep Workflow
  7. Protocol Guidance for Extraction of Ultra-High Molecular Weight (UHMW) Genomic DNA for Ultra-Long (UL) Read NGS Sequencing applications in Oxford Nanopore Technologies® workflows

Manuals

The Product Manual includes details for how to use the product, as well as details of its formulation and quality controls.

Usage & Guidelines

Application Notes

FAQs & Troubleshooting

FAQs

  1. How does excess residual protein in blood and tissue preps affect the purification process?
  2. Which measurement system is best used for assessing the concentration of HMW DNA?
  3. I dropped a few of my glass beads. Can I clean them, and do you supply extra?
  4. Is there anything special about the Monarch DNA Capture Beads, or can I use any glass beads?
  5. Are the Monarch HMW DNA Extraction kits compatible with samples stored in Monarch DNA/RNA Protection Reagent, RNAlater, DNA/RNA Shield etc.?
  6. How do I know that my HMW DNA has attached to glass beads in the Monarch HMW DNA Extraction Kits?
  7. Is there any benefit to adding in a size selection (e.g., Circulomics® Short Read Eliminator) following extraction?
  8. Can I still use the Monarch HMW DNA Extraction Kits if I do not have a thermal mixer?
  9. Can I use the Monarch HMW DNA Extraction Kits for processing plant samples?
  10. Can I use the Monarch HMW DNA Extraction Kits for processing insect samples?
  11. Can the Monarch HMW DNA Extraction Kit be used for processing yeast and/or fungal samples?
  12. Can the Monarch HMW DNA Extraction Kits be used to process marine samples, including marine invertebrates?
  13. Can the Monarch HMW DNA Extraction Kits be used to process human Buffy coat?
  14. Can the Monarch HMW DNA Extraction Kits be used to process mouthwash samples?
  15. Can the Monarch HMW DNA Extraction Kits be used to process environmental or fecal samples for metagenomic studies?
  16. Can the Monarch HMW DNA Extraction Kits be used to isolate BAC DNA?
  17. How do you suggest homogenizing tougher tissues, like ear punches or muscle? Can a sonicator be used for tissue homogenization?
  18. Does the kit work with frozen tissue, tissue stored in preservatives (ethanol, DMSO-salt/DESS, or RNAlater®), FFPE samples, or OCT-preserved tissues?
  19. Do you see different fragmentation results when using the pestle versus the rotor-stator homogenizer for tissue homogenization?
  20. Do you have any PacBio Sequencing results from DNA extracted from tissue samples with the Monarch HMW DNA Extraction Kits?
  21. Does the Monarch HMW DNA Extraction workflow work for single cells?
  22. Can you use the DNA isolated with the Monarch HMW DNA Extraction Kits in Southern blots?
  23. Can the Monarch HMW DNA Extraction Kits be used to process nematodes?
  24. I am having trouble dissolving my HMW DNA after isolation. Do you have any tips on increasing the solubility?
  25. The enzymes in the kit were not stored at -20°C right away. Will they still work?
  26. There is a precipitate in the Proteinase K enzyme tube, is this normal?
  27. Which Monarch® columns and bead retainers can be used with which Monarch collection tube?
  28. I noticed the collection tube dimensions has changed slightly in the Monarch® HMW DNA Extraction Kit for Cells & Blood (NEB #T3050) and the Monarch HMW DNA Extraction Kit for Tissue (NEB #T3060). Will this impact performance?
  29. I notice that I'm applying force to fit the column into a collection tube. Should I be doing this? What collection tubes are compatible with columns?

Troubleshooting

Quality, Safety & Legal

Quality Assurance Statement

Quality Control tests are performed on each new lot of NEB product to meet the specifications designated for it. Specifications and individual lot data from the tests that are performed for this particular product can be found and downloaded on the Product Specification Sheet, Certificate of Analysis, data card or product manual. Further information regarding NEB product quality can be found here.

Specification Change Notifications

Effective March 18,2024, collection tube dimensions modified and component numbers changed.

Effective March 14, 2024: Proteinase K, Molecular Biology Grade component number has changed with the concentration changing from 800U/ml to 20 mg/ml.
