Product Class: Kit

NEBNext® Multiplex Oligos for Illumina® (96 Unique Dual Index Primer Pairs)

Product Introduction

NEBNext® Multiplex Oligos provide adaptors and primers to enable high yield multiplex Illumina® library production. The unique hairpin loop structure of the NEBNext Adaptor minimizes adaptor-dimer formation, and NEBNext index PCR primers enable index incorporation during library amplification. This first set of UDI primer pairs (Set 1 of 5) includes 96 pre-mixed unique pairs of i5 and i7 index primers, packaged in a single-use 96-well plate with a pierceable foil seal.

For additional information on available indices and formats for multiplexing, please refer to the NEBNext Multiplex Oligos Selection Chart.

  • Allows complete filtering of index-hopped reads
  • High efficiency adaptor ligation
  • Minimized adaptor-dimer formation
  • Includes index primers for library multiplexing
  • Increased sample identification specificity
  • This set (Set 1) may be combined with sets 2, 3, 4 and 5 for 480 barcodes
Catalog # Size Concentration
E6440S 96.0 reactions
E6440L 384.0 reactions

Product Information

Description

NEBNext® Adaptor ligates with increased efficiency to end-repaired, dA-tailed DNA, due to its novel hairpin-loop structure. The loop includes a uracil (U), which is removed by treatment with USER® Enzyme (a mix of UDG and Endo VIII), opening the loop and making it available as a substrate for PCR. During PCR, NEBNext index primers can be incorporated, thereby enabling multiplexing. This kit includes 96 pre-mixed unique pairs of i5 and i7 index primers, packaged in a single-use 96-well plate with a pierceable foil seal.

NEBNext Oligos are for use with NEBNext products or other standard Illumina-compatible library preparation protocols. Additional options are available in unique dual barcodes (NEB #E6440), dual barcode sets (NEB #E7600, NEB #E7780), single primer sets (in 12- and 96- index formats; NEB #E7335, NEB #E7500, NEB #E7710, NEB #E7730, NEB #E6609), and an option compatible with EM-seq™ and bisulfite sequencing (NEB #E7140).

Workflow:

NEBNext Adaptors enable high-efficiency adaptor ligation and high library yields, with minimized adaptor-dimer formation, and are designed for use in library prep for DNA, ChIP DNA and RNA (but not Small RNA). A novel hairpin loop structure ligates with increased efficiency to end-repaired, dA-tailed DNA. The loop contains a U, which is removed by USER Enzyme (a combination of UDG and Endo VIII), thereby becoming a substrate for PCR, when barcodes can be incorporated by use of the NEBNext index primers. The 96 8-base index primer pairs included in this kit are pre-mixed and are packaged in a single-use 96-well plate with a pierceable foil seal.

For multiplexing with 480 indices, combine this set with NEB #E6442, NEB #E6444, NEB #E6446 and NEB #E6448.


Figure 1: Workflow demonstrating the use of NEBNext Multiplex Oligos for Illumina (96 Unique Dual Index Primer Pairs)



Figure 2: Use of NEBNext Adaptor and Unique Dual Index Primer Pairs substantially increases library yields and minimizes adaptor-dimers

16 libraries were prepared with 100 ng of Human NA19240 genomic DNA (Coriell Institute), using the NEBNext Ultra II FS DNA library prep kit. Adaptors and primers were from either the IDT® for Illumina® –TruSeq® DNA UD Indexes (Illumina # 20022370), or the NEBNext Multiplex Oligos for Illumina (96 Unique Dual Index Primer Pairs). After 4 PCR cycles, libraries were quantified on an Agilent® TapeStation® 4000. A) Average library yields for the 8 libraries made using each workflow show 60% higher yield when the NEBNext Adaptor and Unique Dual Index Primer Pairs are used. B) TapeStation traces of 16 libraries show the presence of adaptor-dimer (indicated by the orange arrow) with the libraries made using IDT for Illumina adaptors and primers, which is absent in the libraries prepared using NEBNext adaptors and primers, which also have higher yields.



Figure 3: Libraries amplified with NEBNext 96 Unique Dual Index Primer Pairs cluster evenly on the Illumina® NovaSeq™ 6000

96 libraries produced using the NEBNext Ultra II FS DNA library prep kit (Figure 1) and the NEBNext 96 Unique Dual Index Primer Pairs were pooled at equimolar concentrations and sequenced on the Illumina NovaSeq 6000 instrument (2 x 150 bp). The total number of reads from all libraries were summed, and the fraction of the total reads contributed by each library was determined (expected fraction per library=1.04%). All 96 libraries clustered efficiently and were represented at approximately the expected frequency.



Figure 4: NEBNext 96 Unique Dual Index Primer Pairs amplify libraries with equal efficiency

Human NA19240 genomic DNA (Coriell Institute) was used to prepare 96 libraries using either the NEBNext Ultra II FS DNA library prep kit, Covaris-sheared DNA with the NEBNext Ultra II DNA library prep kit, the Ultra II DNA library prep kit combined with bisulfite conversion, or the NEBNext Ultra II Directional RNA library prep kit. Libraries were PCR-amplified using the NEBNext 96 Unique Dual Index Primer Pairs to produce libraries containing unique i5 and i7 indices. Library yields were quantified (Agilent® TapeStation® 4200) and normalized by summing the total yield of all 96 libraries and calculating the contribution from each library (expected fraction per library = 1.04%). Library amplification efficiency was robust with each library prep method and efficiency was uniform across all 96 unique index primer combinations. Each bar represents the average of at least 2 technical replicates.



Figure 5: Unique Dual Index Primer Pairs allow identification and discarding of index-hopped reads.

One set of the 96 NEBNext Ultra II FS DNA libraries (Figure 2) was used to assess the accuracy of read classification and filtering of barcode-hopped reads using unique dual indices. The 96 libraries were pooled at equimolar concentration and the pool was sequenced on both the NovaSeq 6000 (2x150 bp) and MiSeq® (2 x 76 bp) instruments. Reads were demultiplexed using the Picard ExtractIlluminaBarcodes tools considering both indices, and classified into the following categories:
  • Demultiplexed reads: expected i5 and i7 barcode combination
  • Identified index hopping: expected barcodes, but not in expected combination
  • Dark clusters: N or G reads (not observed on MiSeq due to 4-color chemistry)
  • Phi X: any reads matching the universal primer sequence (not present in MiSeq experiment)
  • Other: any remaining reads not fitting into the above categories
Demultiplexing with a single i5 or i7 index (or a non-unique combination of i5 and i7) incorrectly assigns ~5% of reads on the NovaSeq and 0.6% of reads on the MiSeq, leading to misassignment of reads between samples and problems for downstream analyses. Unique dual indices successfully identify and enable rejection of reads of unknown provenance during demultiplexing.


Figure 6: Libraries amplified with 384 primer pairs from NEBNext Multiplex Oligos for Illumina (96 Unique Dual Index Primer Pairs Set 1-4) cluster evenly on the Illumina NovaSeq™ 6000



384 libraries produced using the NEBNext Ultra II DNA Library Prep Kit (NEB #E7645) and the NEBNext Multiplex Oligos for Illumina (96 Unique Dual Index Primer Pairs Set 1-4) were pooled at equimolar concentrations and sequenced on the Illumina NovaSeq® 6000 instrument. The total number of reads from all libraries were summed, and the fraction of the total reads contributed by each library was determined (expected fraction per library = 0.26 %). All 384 libraries clustered efficiently and were represented at approximately the expected frequency.


This product is related to the following categories:
NEBNext® Multiplex Oligos (Adaptors & Primers) Products,
Next Generation Sequencing Library Preparation Products,

Kit Components

Kit Components

The following reagents are supplied with this product:

NEB # Component Name Component # Stored at (°C) Amount Concentration
  • E6440S     -20
      USER® Enzyme E6610AVIAL -20 1 x 0.288 ml Not Applicable
      NEBNext® 96 Unique Dual Index Primer Pairs Plate (L) E6441AVIAL -20 1 x 10 μl/well 10 µM
      NEBNext® Adaptor for Illumina® E6612AVIAL -20 1 x 0.96 ml 15 µM
  • E6440L     -20
      USER® Enzyme E6610AAVIAL -20 2 x 0.576 ml Not Applicable
      NEBNext® 96 Unique Dual Index Primer Pairs Plate (L) E6441AVIAL -20 4 x 10 μl/well 10 µM
      NEBNext® Adaptor for Illumina® E6612AVIAL -20 4 x 0.96 ml 15 µM

Properties & Usage

Protocols, Manuals & Usage

Protocols

  1. Where can I find protocols for using NEBNext® Multiplex Oligos for Illumina® (96 Unique Dual Index Primer Pairs)? (NEB #E6440, #E6442, #E6444, #E6446, #E6448)

Manuals

The Product Manual includes details for how to use the product, as well as details of its formulation and quality controls.

Usage & Guidelines

Tools & Resources

Selection Charts

FAQs & Troubleshooting

FAQs

  1. Are NEBNext adaptors and primers for Illumina validated in Next Generation Sequencing Workflows?
  2. What is the concentration of the adaptor and primers in the NEBNext Multiplex Oligos kits?
  3. Can I use the 96-well primer plate to do my PCR reactions when using the NEBNext® Multiplex Oligos for MGI® (Dual Index Primer Pairs Set 1) (NEB #E9640)?
  4. How many reactions worth of primer are in each well?
  5. Is the NEBNext adaptor methylated?
  6. Can I perform single read runs and still get both index sequences? Can I run both single read and paired-end recipes with dual-indexed libraries?
  7. Are dual indexed libraries compatible with single end sequencing?
  8. How many indices are available with NEBNext® Multiplex Oligos for Illumina® (96 Unique Dual Index Primer Pairs) (NEB #E6440, E6442, E6444, E6446, and E6448)?
  9. Can the NEBNext Multiplex Oligos for Illumina (96 Unique Dual Index Primer Pairs) (NEB #E6440, #E6442, #E6444, #E6446, and #E6448) be used to address "index hopping" with Illumina patterned flow cells?
  10. Where can I find the sample sheets for these Multiplex Oligos?
  11. Which sets of NEBNext Unique Dual Index Primer Pairs can be combined in a single Illumina sequencing run?
  12. How do I use the NEB provided Sample Sheet for my specific instrument?
  13. What sequences need to be trimmed for NEBNext libraries that are sequenced on an Illumina instrument?
