PNGase F
Product informationCode | Name | Size | Quantity | Price | |
---|---|---|---|---|---|
P0704S |
PNGase F |
15.000 units ( 500000 units/ml ) | - | Unavailable in your region | |
P0704L |
PNGase F |
75.000 units ( 500000 units/ml ) | - | Unavailable in your region |
PNGase F
Product Introduction
PNGase F is the most effective enzymatic method for removing almost all N-linked oligosaccharides from glycoproteins. PNGase F is an amidase, which cleaves between the innermost GlcNAc and asparagine residues of high mannose, hybrid, and complex oligosaccharides.
- Leaves N-glycan core oligosaccharides intact and suitable for further analysis
- Non-recombinant with no detectable endoglycosidase F1, F2 or F3 contamination
- ≥ 95% purity, as determined by SDS-PAGE and intact ESI-MS
- Stored in 50% glycerol
- Optimal activity and stability for up to 24 months
- Can be used under native or denaturing conditions
Catalog # | Size | Concentration |
---|---|---|
P0704S | 15000.0 units | 500000 units/ml |
P0704L | 75000.0 units | 500000 units/ml |
Featured Videos
View Video Library-
Overview of Glycobiology
- Product Information
- Protocols, Manuals & Usage
- Tools & Resources
- FAQs & Troubleshooting
- Citations & Technical Literature
- Quality, Safety & Legal
- Other Products You May Be Interested In
Product Information
Description
Peptide -N-Glycosidase F, also known as PNGase F, is an amidase that cleaves between the innermost GlcNAc and asparagine residues of high mannose, hybrid, and complex oligosaccharides from N-linked glycoproteins (1)
Product Source
PNGase F is purified from Flavobacterium meningosepticum (3) and it is free of proteases and Endo F activities.Glycosidase Recognition Site
- This product is related to the following categories:
- Endoglycosidases Products,
- Proteome Analysis Products,
- This product can be used in the following applications:
- Expression Systems,
- Glycan Sequencing,
- Proteomics,
- Recombinant Glycoprotein Expression, Glycoprotein Analysis
Reagents Supplied
Reagents Supplied
The following reagents are supplied with this product:
NEB # | Component Name | Component # | Stored at (°C) | Amount | Concentration | |
---|---|---|---|---|---|---|
Properties & Usage
Unit Definition
One unit is defined as the amount of enzyme required to remove > 95% of the carbohydrate from 10 µg of denatured RNase B in 1 hour at 37°C in a total reaction volume of 10 µl.Unit Definition Assay:
10 µg of RNase B are denatured with 1X Glycoprotein Denaturing Buffer (0.5% SDS, 40 mM DTT) at 100°C for 10 minutes. After the addition of NP-40 and GlycoBuffer 2, two-fold dilutions of PNGase F are added and the reaction mix is incubated for 1 hour at 37°C. Separation of reaction products are visualized by SDS-PAGE.
1X Glycoprotein Denaturing Buffer
0.5% SDS
40 mM DTT
1X NP-40
1% NP-40 in MilliQ-H2O
Reaction Conditions
1X GlycoBuffer 2
Incubate at 37°C
1X GlycoBuffer 2
50 mM Sodium Phosphate
(pH 7.5 @ 25°C)
Storage Buffer
20 mM Tris-HCl
50 mM NaCl
5 mM EDTA
50% Glycerol
pH 7.5 @ 25°C
Heat Inactivation
75°C for 10 minutesMolecular Weight
Apparent: 36000 daltonsApplication Features
- Removal of high mannose N-glycans from glycoproteins
Related Products
Companion Products
Product Notes
- Since PNGase F activity is inhibited by SDS, it is essential to have NP-40 present in the reaction mixture. Why this non-ionic detergent counteracts the SDS inhibition is unknown at present.
- To deglycosylate a native glycoprotein, longer incubation time as well as more enzyme may be required.
- PNGase F will not cleave N-linked glycans containing core α1-3 Fucose.
- Typical reaction conditions: Please see Protocols
References
- Maley, F. et al. (1989). Anal. Biochem. 180, 195-204.
- Tretter, V. et al. (1991). Eur. J. Biochem.. 199, 647-652.
- Plummer, T.H. Jr. and Tarentino, A.L. (1991). Glycobiology. 1, 257-263.
Protocols, Manuals & Usage
Protocols
Usage & Guidelines
Application Notes
- AppNote_Remove-iT_PNGase_F_Effective_Release_and_Recovery_of_Neutral_and_Sialylated_N-glycans
- AppNote_Glycan_Analysis_of_Murine_IgG_by_Enzymatic_Digestion_with_Endo_S_and_PNGase_F
- AppNote_Proteomics_Fast_and_Efficient_Antibody_Deglycosylation_using_Rapid_PNGase_F
- AppNote_Glycan_Analysis_of_Murine_IgG2a_by_Enzymatic_Digestion_with_PNGase_F_and_Trypsin
- Characterization of Glycans from Erbitux®, Rituxan® and Enbrel® using PNGase F (Glycerol-free), Recombinant
- Enzymatic removal of N- and O-glycans using PNGase F or the Protein Deglycosylation Mix
- Glycan Analysis of Murine IgG by Enzymatic Digestion with Endo S and PNGase F Followed by Mass Spectrometric Analysis
- Remove iT PNGase F Effective Release and Recovery of Neutral and Sialylated N glycans
- Glycan Analysis of Murine IgG2a by Enzymatic Digestion with PNGase F and Trypsin, Followed by Mass Spectrometric Analysis
- A Fast One-Step Digestion of DNA or RNA for Global Detection and Characterization of Nucleotide Modifications
Tools & Resources
Selection Charts
FAQs & Troubleshooting
FAQs
- Is PNGase F compatible with downstream analysis such as HPLC and Mass Spectrometry?
- What happens to the asparagine after PNGase removes the sugar?
- Why is my immunoprecipitated (IP) protein degraded? When I denature and add SDS all I see on my SDS-PAGE is a smear or no protein?
- What are the typical reaction conditions for PNGase F?
- Does PNGase F work in Urea?
- How do I inhibit PNGase F?
- How much PNGase F should I use to remove my carbohydrate under native conditions?
- I tried the PNGase F on my glycoprotein and didn't see removal of the carbohydrate. What could be the problem?
- What is the difference between PNGase F, Endo H and O-Glycosidase?
- Do detergents inhibit exoglycosidases/endoglycosidases?
- Why have the NEB Glycosidase enzymes changed reaction buffers? What are the new reaction buffers and can I still use an enzyme with its old buffer? Where can I find the composition of the old buffers?
- What are Glycosidases and their uses?
- What is a good endoglycosidase substrate?
Tech Tips
You can use this enzyme under native or denaturing conditions
Under native conditions we recommend adding more enzyme and using longer incubation times
PNGase F activity is inhibited by SDS, therefore under denaturing conditions it is essential to have NP-40 present in the reaction mixture in a 1:1 ratio.
PNGase F will not cleave N-linked glycans containing core a1-3 Fucose (PNGase A must be used in this instance)
Enzyme activity varies at different temperatures: 37°C - 100%; 30°C - 100%; 23°C - 65%; 17°C - 40% and 3°C - 0%
A good positive control substrate is RNase B
Citations & Technical Literature
