Heat sealing membrane, limits evaporation, peelable, pierceable; suitable for cell culture, seed and insect storage

Heat sealing offers a 100% effective method for plate sealing for a complete seal integrity, as well as being quick and cost effective.

The Gas Permeable Heat Seal Mark 2 is made from a woven material and is designed for use in cell culture, due to its porous nature. The small pore size - <20 µm - of this material enables gas exchange, per 24 hours of >20 g/m², whilst evaporation is reduced to a minimum.

The seal is compatible with polypropylene, polystyrene and cyclic olefin copolymer (COC) plates. It can be removed by peeling, or it can be pierced with a pipette tip manually, using a liquid handling robot or with our Pierce Plate (4ti-0398).

Gas Permeable Heat Seal Mark 2 can be utilised for effective overnight incubations, during which it demonstrates significant reductions in evaporation compared to lids. It can also be used for insect and seed storage as it enables gas exchange, whilst providing an inert surface with no adhesive to interfere with the well contents.

Gas Permeable Heat Seal Mark 2 is available as sheets, for use with manual and semi-automated sealers, such as our 4s3™ Semi-Automatic Sheet Heat Sealer, and in multiple roll formats compatible with specified automated heat sealers, such as our a4S Automatic Roll Heat Sealer.

Features

• Peelable
• Available sterile from stock - sterile variations have /ST added to the end of their product code
• Seals polypropylene, polystyrene and cyclic olefin copolymer (COC) plates
• Seal integrity range: -20 °C to 80 °C
• Suitable for cell culture, overnight incubations, as well as insect and seed storage
• Gas permeability rate: 180 m³/m²/day
• Moisture vapour transmission rate: 20 g/m²/day
• Free from DNase, RNase, and human genomic DNA, endotoxin/pyrogen free
• Sheet dimensions: 125 x 78 mm, to fit all standard SBS footprint PCR and qPCR plates, microplates, assay and storage plates, from 12 well to 1536 well
• Rolls: available in a variety of roll dimensions, to suit your choice of automatic heat sealing equipment
• Autoclavable (121 °C)

Click here for more information about our Heat Sealing product range.
