T7 Endonuclease I
NEB2 cloned at NEB recombinant 37 No

Authenticase® (NEB #M0689) now available for improved genome editing mutation detection.

Product Introduction

  • DNA Endonuclease
  • Catalyzes the cleavage of DNA mismatches and non-β DNA structures including Holliday junctions and cruciform leaving 3'-OH and 5'-phosphate
  • Best at C mismatches and does not recognize all DNA mismatches
  • To a lesser extent cleaves across a nick in dsDNA
  • Key enzyme for use in genome editing mutation detection workflows
  • Also available in convenient kit format: EnGen Mutation Detection Kit (NEB #E3321)
  • Need help finding the right exonuclease for your experiments? Try Exo Selector
Catalog # Size Concentration
M0302S 250.0 units 10000 units/ml
M0302L 1250.0 units 10000 units/ml

Product Information

Description

Highlights

  • Isolated from a recombinant source
  • Supplied with 10X Reaction Buffer
  • Recognizes non-perfectly matched DNA
T7 Endonuclease I recognizes and cleaves non-perfectly matched DNA, cruciform DNA structures, Holliday structures or junctions, heteroduplex DNA and more slowly, nicked double-stranded DNA. The cleavage site is at the first, second or third phosphodiester bond that is 5´ to the mismatch. The protein is the product of T7 gene 3.

Product Source

An E. coli strain that carries a fusion of maltose binding protein and T7 Endonuclease I (T7 Endo I).
This product is related to the following categories:
Mutation Detection Reagents and Kits Products,
Genome Editing Products,
Exonucleases and Non-specific Endonucleases Products,
DNA Repair Enzymes and Structure-specific Endonucleases Products,
This product can be used in the following applications:
Whole Genome Amplification & Multiple Displacement Amplification,
Genome Editing Applications

Reagents Supplied

Reagents Supplied

The following reagents are supplied with this product:

NEB # Component Name Component # Stored at (°C) Amount Concentration

Properties & Usage

Unit Definition

One unit is defined as the amount of enzyme required to convert > 90% of 1 μg of supercoiled cruciform pUC(AT) to > 90% linear form in a total reaction volume of 50 μl in 1 hour at 37°C.

Reaction Conditions

1X NEBuffer™ 2
Incubate at 37°C

1X NEBuffer™ 2
50 mM NaCl
10 mM Tris-HCl
10 mM MgCl2
1 mM DTT
(pH 7.9 @ 25°C)

Storage Buffer

20 mM Tris-HCl
200 mM NaCl
1 mM DTT
0.1 mM EDTA
50% Glycerol
0.15% Triton® X-100
pH 7.5 @ 25°C

Heat Inactivation

No

Application Features

  • Resolve four-way junction or branched DNA
  • Detect or cleave heteroduplex and nicked DNA
  • Randomly cleave linear DNA for shot-gun cloning

Product Notes

  1. T7 Endonuclease I is a structure-selective enzyme. It acts on a variety of DNA substrates with different specific activities.
  2. It is important to control the amount of enzyme and the reaction time used for cleavage of a particular substrate.
  3. Temperatures above 42°C cause an increase in nonspecific nuclease activity and should be avoided.
  4. pUC(AT) is derived from pUC19 with a modification of the polylinker between the EcoRI site and the PstI site.

References

  1. Xu, M. -Q. and Evans, T.C. (2001). Methods. 24, 257-277.
  2. Parkinson, M.J. and Lilley. D.M.J. (1997). J. Mol. Biol.. 270, 169-178.
  3. White, M.F. et al. (1997). J. Mol. Biol.. 269, 647-664.
  4. Hadden, J.M. et al. (2001). Nat. Struct. Biol.. 8, 62-67.
