G(5')ppp(5')G RNA Cap Structure Analog

Product Introduction

  • Co-transcriptional capping with T7, SP6 and T3 RNA polymerases
  • Synthesis of unmethylated G-capped RNA
Catalog # Size Concentration
S1407S 1 µmol
S1407L 5 µmol

Featured Videos

View Video Library
  • RNase_Contamination_Anim_720x405

    Avoiding RNase Contamination

Product Information

Description

The 5´ terminal m7G cap present on most eukaryotic mRNAs promotes translation in vitro at the initiation level (1,2,3). For most RNAs, elimination of the cap structure causes a loss of stability, especially against exonuclease degradation (4), and a decrease in the formation of the initiation complex of mRNAs for protein synthesis (4,5). Certain prokaryotic mRNAs containing a 5´ terminal cap structure are translated as efficiently as or more efficiently than eukaryotic mRNAs in a eukaryotic cell-free protein synthesizing system (5). Also a cap requirement has been observed for splicing eukaryotic substrate RNAs (6).

A method using E. coli RNA Polymerase primed with m7G(5´)ppp(5´)G or m7G(5´)ppp(5´)A for an efficient in vitro synthesis of capped RNAs has been developed by Contreas (7). Larger amounts of capped RNAs are produced by transcription systems using SP6 RNA polymerase primed with m7G(5´)ppp(5´)G (6).

Figure 1: Structure of G(5´)ppp(5´)G RNA Cap Structure Analog (NEB #S1407)

Structure of G(5')ppp(5')G RNA Cap Structure Analog

Sequence

G(5')ppp(5')G
This product is related to the following categories:
RNA Capping,

Reagents Supplied

Reagents Supplied

The following reagents are supplied with this product:

NEB # Component Name Component # Stored at (°C) Amount Concentration

Properties & Usage

Supplied As

Dried Sodium Salt

Suggested Working Concentration

10mM

Recommended Resuspension Volume

100 μl

Product Notes

  1. Addition of 100 µl of water gives approximately a 10 mM solution.

References

  1. Shatkin, A.J. (1978). Cell. 9, 645-653.
  2. Fillipowicz, W. (1978). FEBS Lett. . 96, 1-11.
  3. Banerjee, A.K. (1980). Microbiol. Rev.. 1980, 175-205.
  4. Miura, K. (1981). Adv. Biophys. . 14, 205-238.
  5. Shatkin, A.J. et al. (1977). Nucl. Acids Res.. 4, 3065-3081.
  6. Konarska, M.M. et al. (1984). Cell. 38, 731-736.
  7. Contreas, R. et al. (1982). Nucl. Acids Res. 10, 6353-6363.
  8. Paterson, B.M. and Rosenberg, M. (1979). Nature. 279, 696-701.

Protocols, Manuals & Usage

Protocols

  1. Capped RNA Synthesis (E2050)
